NAS1096-3-18 - Screw

Part number NAS1096-3-18 is an aerospace flush head machine screw with Phillips recess drive, manufactured to NAS standards for high-strength fastening applications requiring a smooth, countersunk installation.

Specifications

• Type: Flush Head Machine Screw
• Thread Size: #3
• Shank Length: 28.6 mm
• Head Diameter: 4.77 mm
• Overall Length: 31.57 mm
• Head Style: 100° countersunk flush head
• Drive Type: Phillips cross recess
• Thread Type: Fine machine thread
• Material: Corrosion-resistant steel alloy
• Finish: Aerospace-grade cadmium/zinc protective coating

Features

• Flush countersunk head provides smooth aerodynamic surface
• Phillips recess enables secure installation and removal
• Extended threaded shank for deeper fastening applications
• Fine-thread design delivers reliable clamping performance
• Corrosion-resistant finish suitable for aircraft environments
• Precision NAS-standard aerospace hardware construction
