MS35206-205 - Screw

Part number MS35206-205 is a Phillips oval head machine screw manufactured to military standard specifications for aerospace, avionics, and precision fastening applications requiring a semi-flush finished installation.

Specifications

• Type: Oval Head Machine Screw
• Drive Type: Phillips recessed drive
• Shank Length: 8.78 mm
• Head Diameter: 2.14 mm
• Overall Length: 10.44 mm
• Head Style: Oval raised countersunk head
• Material: Corrosion-resistant steel / alloy steel
• Finish: Cadmium or zinc chromate aerospace finish
• Thread Type: Fine machine thread

Features

• Oval countersunk head provides a smooth, low-profile installed appearance
• Phillips drive allows controlled torque application and easy installation
• Fine-thread design improves holding strength and vibration resistance
• Corrosion-resistant aerospace finish suitable for demanding environments
• Precision manufactured to MS military standards for interchangeability and reliability
• Designed for lightweight assemblies and precision fastening applications
