MS20615-4MP7 - Rivet

Part number MS20615-4MP7 is a flush head drive screw / rivet-type pin fastener used in aerospace and aircraft sheet metal applications where a smooth flush surface is required.

Specifications

• Type: Flush head drive pin / rivet fastener
• Head Style: 100° countersunk flush head
• Diameter: No. 4 size (1/8 in. / approx. 3.18 mm shank diameter)
• Length: 7/16 in. (approx. 11.11 mm)
• Material: Corrosion-resistant steel or alloy steel (per MS20615 specification)
• Finish: Cadmium plated / corrosion resistant finish
• Drive Type: Hammer/drive installation style
• Specification Standard: MS20615 military aerospace standard

Features

• Flush head provides smooth aerodynamic surface
• Permanent mechanical fastening design
• High shear strength and vibration resistance
• Suitable for aircraft skin and structural assemblies
• Corrosion-resistant plated finish for aerospace environments
