MS20008-24 - Bolt

Socket head shoulder bolt  featuring a precision ground shoulder and a partially threaded end. Designed for applications requiring accurate alignment, pivoting, or spacing, while allowing secure fastening with an internal hex drive.

Dimensions

• L (Shank Length): 58.20 mm
• W (Head Diameter): 12.66 mm
• OL (Overall Length): 71.20 mm

Configuration

• Type: Shoulder bolt (socket head)
• Thread: Partially threaded
• Drive: Internal hex (Allen)
• Point: Flat end

Features

• Precision shoulder for accurate alignment and load-bearing applications
• Internal hex drive for high torque installation in tight spaces
• Partially threaded design separates shear load from threads
• Corrosion-resistant finish
• Aerospace/military-grade materials and tolerances
