CCR274CS-4-7P1 - Rivet

Part number CCR274CS-4-7P1 is a CherryLOCK® structural blind rivet designed for aerospace structural fastening applications where installation access is limited to one side of the assembly.

The CCR274CS series features a 100° flush countersunk head for flush aerodynamic surfaces and utilizes a mechanically locked stem system for high structural strength and vibration resistance.

Specifications

• Type: Structural blind rivet
• Series: CherryLOCK CCR274CS
• Head Style: 100° flush countersunk head
• Diameter: -4 size (1/8 in nominal diameter)
• Grip Length: -7 grip range
• Installation: Blind installation using CherryLOCK tooling
• Stem Locking: Mechanical locking collar system

Features

• Aerospace structural-grade blind fastener
• Flush aerodynamic head configuration
• High shear and tensile strength
• Positive mechanical stem retention
• Excellent vibration resistance
• One-sided installation capability
• Corrosion-resistant aerospace alloy construction
• Commonly used in aircraft skins, structural panels, and airframe assemblies
